Product Summary
The QM30TF-HB is a Mitsubishi transistor module. The applications of the QM30TF-HB are: Inverters, Servo drives, DC motor controllers, NC equipment, Welders.
Parametrics
QM30TF-HB absolute maximum ratings: (1)Collector-emitter voltage: 600V; (2)Collector-emitter voltage: 600V; (3)Collector-base voltage: 600V; (4)Emitter-base voltage: 7V; (5)Collector current: 30A; (6)Collector reverse current: 30A; (7)Collector dissipation: 250W; (8)Base current: 1.8A; (9)Surge collector reverse current (forward diode current): 300A; (10)Junction temperature: –40~+150℃; (11)Storage temperature: –40~+125℃; (12)Isolation voltage: 2500V.
Features
QM30TF-HB features: (1)IC Collector current: 30A; (2)VCEX Collector-emitter voltage: 600V; (3)hFE DC current gain: 750.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 QM30TF-HB |
Other |
|
Data Sheet |
Negotiable |
|
||||
