SCX100DNC

Low cost compensated pressure sensor, 300 Microvolt, 4.0 kOhm, 100 Microsec, SIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $20.00~60.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $20.00~60.00

PartNumber:: SCX100DNC

Brand:: Honeywell Solid State Electronics Center - Honeywell | Pack: SIP | D/C: 12+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Mark's store

(China (Mainland))

2000

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-03

From Other Seller

Part Number:SCX100DNC
US $20.00 - 60.00
BD9774HFP

US $0.70 - 1.20 / Piece
(0) Remove
PIC16F917-I/P(PIC16F917-IP)

US $1.60 - 2.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SCX100DNC is a Low cost compensated pressure sensor. The SCX100DNC provides a very cost-effective solution for pressure applications that require operation over wide temperature range. These internally calibrated and temperature compensated sensor was specifically designed to provide an accurate and stable output over a 0 ℃ to 70 ℃ [32 °F to 158 °F] temperature range. The SCX100DNC is intended for use with non-corrosive, non-ionic working fluids such as air, dry gases and the like.

Parametrics

SCX100DNC absolute maximum ratings: (1)Zero Pressure Offset: -300 to 300 Microvolt; (2)Combined Pressure Non-Linearity and Pressure Hysteresis: ±0.1 to ±0.5 % FSO; (3)Temperature Effect on Span 0 ℃ to 70 ℃ [32 °F to 158 °F]: ±0.2 to ±0.1 % FSO; (4)Temperature Effect on Offset 0 ℃ to 70 ℃ [32 °F to 158 °F]: ±100 to ±500 Microvolt; (5)Repeatability: ±0.2 to ±0.5 % FSO; (6)Input Resistance: 4.0 kOhm; (7)Output Resistance: 4.0 kOhm; (8)Common Mode Voltage: 5.8 6.0 6.2 Vdc; (9)Response Time: 100 Microsec.; (10)Long Term Stability of Offset and Span: ±0.1 mV.

Features

SCX100DNC features: (1)Precision Temperature Compensation; (2)Calibrated Zero & Span; (3)Small Size; (4)Low Noise; (5)Low Cost (SCX_NC); (6)High Accuracy (SCX_N); (7)High Impedance for Low Power Applications.
