Product Summary
The VI-2N0-EU, with over 8 million shipped, is Vicor’s first generation of zero-current-switching component-level DC-DC converter. Operating at frequencies up to 2 MHz, the VI-2N0-EU offers exceptional power density, efficiency, noise performance, reliability and ease of use. Power Boosters provide a simple, cost effective, off-the-shelf solution for higher power output requirements. One or more boosters may be used to create synchronous arrays capable of supplying several kilowatts of output power. The flexibility of VI-2N0-EU is also available in half-size, half-power VI-J00 MiniMods.
Parametrics
VI-2N0-EU absolute maximum ratings: (1)Inrush charge: 120x10-6; (2)Input reflected ripple current–pp: 10%; (3)Input ripple rejection: 25+20Log( Vin/Vout) dB.
Features
VI-2N0-EU features: (1)Up to 50W/Cubic Inch; (2)UL, CSA, TuV, VDE, BABT, AUSTEL; (3)80-90% Efficiency; (4)Size: 116,8 x 61,0 x 12,7; (5)Remote Sense and Current Limit; (6)OVP, Thermal Shutdown; (7)Logic Disable; (8)Wide Range Output Adjust; (9)Compatible Power Booster Modules; (10)ZCS Power Architecture; (11)Low Noise FM Control; (12)CE Marked.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 VI-2N0-EU |
|
CONVERTER MOD DC/DC 5V 200W |
Data Sheet |
|
|
||||||
|
VI-2N0-EU-B1 |
|
CONVERTER MOD DC/DC 5V 200W |
Data Sheet |
|
|
||||||
|
VI-2N0-EU-F1 |
|
CONVERTER MOD DC/DC 5V 200W |
Data Sheet |
|
|
||||||
|
VI-2N0-EU-F2 |
|
CONVERTER MOD DC/DC 5V 200W |
Data Sheet |
|
|
||||||
|
VI-2N0-EU-F3 |
|
CONVERTER MOD DC/DC 5V 200W |
Data Sheet |
|
|
||||||
|
VI-2N0-EU-F4 |
|
CONVERTER MOD DC/DC 5V 200W |
Data Sheet |
|
|
||||||
|
VI-2N0-EU-S |
|
CONVERTER MOD DC/DC 5V 200W |
Data Sheet |
|
|
||||||
