Product Summary
The UDN2983A is an 8-channel source driver. Recommended for high-side switching applications that benefit from separate logic and load grounds, the UDN2983A encompass load supply voltages 35 to 80 V and output currents to -500 mA. These 8-channel source drivers are useful for interfacing between low-level logic and high-current loads. Typical loads include relays, solenoids, lamps, stepper and/or servo motors, print hammers, and LEDs.
Parametrics
UDN2983A absolute maximum ratings: (1)Output Voltage Range, VCE: 35V to 80V; (2)Input Voltage, VIN: 15V; (3)Output Current, IOUT: -500 mA; (4)Operating Temperature Range, TA: -20℃ to +85℃; (5)Storage Temperature Range, TS: -55℃ to +150℃.
Features
UDN2983A features: (1)TTL, DTL, PMOS, or CMOS Compatible Inputs; (2)500 mA Output Source Current Capability; (3)Transient-Protected Outputs; (4)Output Breakdown Voltage to 80 V; (5)DIP or SOIC Packaging.
