Product Summary
The SKD145/16 is a bridge rectifier. The typical applications of the device include three phase rectifiers for power supplies, input rectifiers for variable frequency drives, rectifiers for DC motor field supplies and battery charge rectifiers.
Parametrics
SKD145/16 maximum rating: (1)Voltage: 1600 V; (2)Nominal Current: 140 A; (3)Topology: 3 phase bridge; (4)Case: SEMIPONT 6; (5)Operating Temperature: 80 ℃.
Features
SKD145/16 features: (1)compact design; (2)Skiip technology: thermal pressure contact, no base plate and no hard mould; (3)two screws mounting; (4)heat transfer and isolation through direct copper board; (5)low resistance in steady-state and high reliability; (6)high surge currents; (7)up to 1800V; (8)UL recoginzed, file no. E63532.
Diagrams
 |
