Product Summary
The SD200R24MSC is a standard recovery diode. Typical Applications of the SD200R24MSC are Converters, Power supplies, Machine tool controls, High power drives, Medium traction applications.
Parametrics
SD200R24MSC absolute maximum ratings: (1)VRRM , maximum repetitive peak reverse voltage: 2400V; (2)VRSM , maximum non-repetitive peak rev. voltage: 2500V; (3)IRRM max.@ TJ = TJ max.: 15mA.
Features
SD200R24MSC features: (1)Wide current range; (2)High voltage ratings up to 2400V; (3)High surge current capabilities; (4)Stud cathode and stud anode version; (5)Standard JEDEC types.
Diagrams
 |
