Product Summary
The SKKT162/12E is a thyristor/diode module. The SKKT162/12E is suitable for DC motor control, temperature control and professional light dimming.
Parametrics
SKKT162/12E absolute maximum ratings: (1)ITAV: 156(110)A when sin, 180, TC=85(100)℃; (2)ID: 190/230A when P3/180F, Ta=35℃, B2/B6; (3)IRMS: 265A when P3/180F, Ta=35℃, W1/W3; (4)ITSM: 5400A when Tvj=25℃, 10ms; 5000A when Tvj=125℃, 10ms; (5)i2t: 145000A2S when Tvj=25℃; 125000A2s when Tvj=125℃; (6)VT: 1.6V max when Tvj=25℃, IT=500A; (7)VT(TO): 0.85V when Tvj=125℃; (8)rT: 1.5mΩ max when Tvj=125℃.
Features
SKKT162/12E features: (1)heat transfer through aluminium oxide ceramic isolated metal baseplate; (2)hard soldered joints for high reliability; (3)UL recognized, file no.63532.
